SNKTDA40 123 8 (PLS)
Evaporator · Series TDA · R404A
Capacity
SC1 · +10 °CAir conditioning · ΔT 8 K · Te +2 °C—
SC2 · 0 °CCold storage · ΔT 8 K · Te −8 °C4.26 kW
SC3 · −18 °CLow temperature · ΔT 7 K · Te −25 °C3.54 kW
SC4 · −25 °CFrozen storage · ΔT 6 K · Te −31 °C2.8 kW
- Product code
- 8194
- Series
- TDA
- Refrigerant
- R404A
- Fan
- 2 × Ø400 mm · 1,400 rpm
- Airflow
- 6,902 m³/h
- Heat transfer surface
- 13.64 m²
- Fin spacing
- 8 mm
- Pipe connections
- 1/2" - 7/8"
- Dimensions (L × W × H)
- 1,638 × 909 × 384 mm
