SNKTDA50 143 8 (PLS)
Evaporator · Series TDA · R404A
Capacity
SC1 · +10 °CAir conditioning · ΔT 8 K · Te +2 °C—
SC2 · 0 °CCold storage · ΔT 8 K · Te −8 °C16.7 kW
SC3 · −18 °CLow temperature · ΔT 7 K · Te −25 °C13.3 kW
SC4 · −25 °CFrozen storage · ΔT 6 K · Te −31 °C10.7 kW
- Product code
- 8242
- Series
- TDA
- Refrigerant
- R404A
- Fan
- 4 × Ø500 mm · 1,400 rpm
- Airflow
- 29,560 m³/h
- Heat transfer surface
- 40.76 m²
- Fin spacing
- 8 mm
- Pipe connections
- 3/4" - 1 3/8"
- Dimensions (L × W × H)
- 3,538 × 1,009 × 408 mm
The quote button opens the contact form filled in with this model.
