SNKTEB40 124 4 (PLS)
Evaporator · Series TEB · R404A
Capacity
SC1 · +10 °CAir conditioning · ΔT 8 K · Te +2 °C11.2 kW
SC2 · 0 °CCold storage · ΔT 8 K · Te −8 °C7.98 kW
SC3 · −18 °CLow temperature · ΔT 7 K · Te −25 °C—
SC4 · −25 °CFrozen storage · ΔT 6 K · Te −31 °C—
- Product code
- 9030
- Series
- TEB
- Refrigerant
- R404A
- Fan
- 2 × Ø400 mm · 1,400 rpm
- Airflow
- 5,866 m³/h
- Heat transfer surface
- 27.74 m²
- Fin spacing
- 4 mm
- Pipe connections
- 5/8" - 7/8"
- Dimensions (L × W × H)
- 1,350 × 492 × 657 mm
The quote button opens the contact form filled in with this model.
